Research Description

The focus of Dr. Muller's research is on the development of new sources of imaging contrasts that provide diagnostically relevant information. Her approach is based on understanding the propagation of ultrasound and elastic waves in biological tissue, and to establish quantitative relationships between ultrasound parameters and the microarchitecture of tissue. Ongoing research in my lab addresses bone, soft tissue and porous materials. The projects include: (1) Bone microarchitecture modelling and assessment; (2) Characterizing vascular networks; (3) The fundamentals of multiple scattering in tissue.

Publications

View publications on Google Scholar

Grants

Novel Ultrasonic Methods for the Assessment of Pulmonary Edema

National Institutes of Health (NIH)(9/01/20 - 8/31/21)

×

Novel Ultrasonic Methods for the Assessment of Pulmonary Edema

Sponsor: National Institutes of Health (NIH)

Start Date: 9/01/20

End Date: 8/31/21

Abstract

We propose to develop novel ultrasound-based methods for the detection and quantification of pulmonary edema due to congestive heart failure (CHF). Ultrasound-based techniques are unsuitable for imaging the lung, due to the large amount of ultrasound wave multiple scattering from the millions of air-liquid interfaces due to alveolar walls and air filled alveoli. We propose to take advantage of this feature. Indeed, each scattering event can be seen as an opportunity for the ultrasound wave to embed information on the micro-architecture of the lung parenchyma. One of us has developed novel software algorithms to calculate the scattering mean free path (SMFP) of ultrasound waves propagated in lung tissue. We hypothesize that the scattering of ultrasound waves by the alveoli can be exploited to characterize the lung parenchyma. Measured SMFP will quantify edema in lung tissue. Three methods are currently used to image lungs to diagnose and follow lung disease: chest X-rays (CXR), CT scan, and nuclear magnetic resonance (NMR) scan. None of these imaging modalities can provide useful information about improving or worsening pulmonary congestion due to CHF. Serial ultrasound lung assessments (not imaging) would be particularly helpful for evaluation of progression or resolution of pulmonary edema due to CHF. We hypothesize that ultrasound scattering can be exploited to characterize the lung parenchyma, and quantify pulmonary edema. This novel hypothesis will be explored by accomplishing these specific aims: Aim 1. To develop ultrasonic methods for the assessment and staging of edema in a rat model of pulmonary edema by using a lung hilar clamp model creating ischemia-reperfusion injury that reliably results in pulmonary edema. Ultrasound methods exploiting the presence of multiple scattering will be implemented in in-vivo edematous and normal lungs. Wet:dry weight ratio (W/D), CT scans, and inflation-fixed lung histology will be used to quantify pulmonary edema. Changes in multiple scattering of ultrasound waves in lung due to edema is not related to the type of edema and protein content. Aim 2. To develop ultrasonic methods for the assessment of pulmonary edema in human lungs. The ultrasonic methods developed in Aim 1 will need to be adapted for use in the human lung by reducing frequency from 8 MHz to 3 to 5 MHz. Aim 3. To validate the proposed methods for quantification of pulmonary edema in human patients. Ten CHF patients will be studied after admission for a CHF exacerbation. Ultrasound parameters will be measured at 5 intercostal spaces on each side serially over 3-5 days and compared to other clinical parameters of pulmonary edema and to ultrasound parameters of normal lung obtained from 5 healthy volunteers. This translational project is responsive to this RFA because it pairs a bioengineer with two clinician-scientists to develop innovative, new, inexpensive methods to quantify pulmonary edema associated with CHF. Future large multicenter studies could be performed to assess utility of an inexpensive novel technology to monitor patients with CHF.
